ASPHALT DISTRIBUTOR TRUCKS

Application: municipal services of cities and towns, civil and industrial road construction.

Purpose: for transporting and evenly distributing hot liquid bituminous materials (tar, bitumen) over the roadbed during road construction or repair.

Equipment set:

• Tanker

• Oil - heating station (110,000 kcal/h)

• Hydraulic system

• Bitumen pump system

• Bitumen circulation system

• Operator panel

• Bitumen tank (thermal tank): 8 000 - 15 000 l

• High pressure diesel burner with fuel consumption of 14-26 kg/h



Main features:

• Connection through the PTO of the truck engine;

• Special design of the ramp spray nozzles to ensure accurate spraying of material from 200 g/m to 2.5 kg/m;

• Manual spraying lance with 3 nozzles and a flexible hose with a length of 3 - 8 m;

• Remote control system for spraying ramp with thermostatic control for easy, safe and accurate spraying of bitumen and bitumen emulsion;

• Possibility of full control of the system from the driver's cab.

• Possibility of remote control;

• High quality bitumen pump and shut-off valves;

• Independence of bitumen consumption from vehicle speed;

• Automatic control of bitumen consumption, depending on the set parameters via the PLC remote control in the driver's cab;

• 4-way valve and technological pipelines of the system, which ensure perfect homogeneity and distribution of bitumen in the ramp.
